STRANDS INSANE DRIVING LIGHT E-MARKED
STRANDS INSANE DRIVING LIGHT E-MARKED
270698

2 LEFT IN STOCK

Type: LED Lights
Brand: Strands

Description:

ALL-BLACK LOOK, UNIQUE DUAL POSITION LIGHT - WHITE/AMBER, EXTREMELY SLIM, ADVANCED TIR OPTICS

Specifications:

  • Type of lamp LED
  • Type of LED LP
  • PCS LED´s High beam: 8pcs (4pcs 10W+4pcs 20W)
    Position Light: 4pcs 0.5W
    Warning Light: 2pcs 3W
  • Voltage (V DC) 9-36V DC
  • Theoretical effect (w) 12V 120
  • Theoretical effect (w) 24V 120
  • Consumption (w) 12V 112
  • Consumption (w) 24V 98
  • Consumption specific function (w) 12V White position light: 1.5
    Amber position light: 1.5
    Warning Light: 6
  • Consumption specific function (w) 24V White position light: 1.5
    Amber position light: 1.5
    Warning Light:6
  • Patterns 1
  • Functions Driving light position light warning light
  • Theoretical lumen 12000
  • Actual lumen 10500
  • 1 LUX @ m 439
  • Kelvin 6000
  • IP-class 68/69K
  • Colour housing Black
  • Colour lens Clear
  • Colour LED´s White amber
  • Beam pattern Combo
  • Position light Yes
  • Connection Cable
  • Cable length (mm) 2500
  • Material bracket Stainless steel
  • Material housing/chassi Aluminium
  • Material lens Polycarbonate
  • Length (mm) 247
  • Depth (mm) 70.7
  • Height (mm) 141
  • Height including bracket (mm) 170.5
  • Operating temperature -40 – +60°C
  • ADR-approved No
  • E-approved  Yes
  • According to regulation ECE R112 R7 R65
  • Reference number 45
  • EMC ECE R10
